Microprocessor based with LCD back lit type.
All zonal status at LCD and LED.
Energy Saving Design for more battery life.
As per IS2189:1999 Fire alarm code of practice.
Modular Construction.
Clear labelled all indicating lamp, control
switch and user instruction based sticker on Front.
Soft Touch programmable Function & Control switch.
Monitor for Mains On, Batt. On, System ON, Charger ON, Fire,
Silence, Earth, Battery Low.
Control Switch: Lamp Test, Evacuate, Silence (Fire/Fault/Power
Fault) and Reset.
Zone display: Fire, Open, Short and Isolate.
Potential Free relay control for signal transfer to remote area.
12VDC auxiliary supply for auto dialer.
24VDC auxiliary supply for other devices.
When mains fails auto change over to battery vice‑versa.
PWM based built in charger with auto cut off.
In built auto charger and battery housing for 7 Ah x 12V ‑2 No.
System ON/OFF switches with protective fuse for AC/DC/Battery.
Fabrication MS with powder coated, Top entry cable entry, front
operable door.
